MAXIMA
Massime prestazioni industriali[vc_row row_type=”row” use_row_as_full_screen_section=”no” type=”full_width” text_align=”left” css_animation=”” bg_type=”bg_color” bg_color_value=”#ffffff” css=”.vc_custom_1494509362085{padding: 20px !important;}”][vc_column][vc_row_inner row_type=”row” type=”full_width” use_row_as_full_screen_section_slide=”no” text_align=”left” css_animation=””][vc_column_inner width=”1/2″][vc_single_image image=”1358″ img_size=”full” onclick=”link_image” qode_css_animation=””][/vc_column_inner][vc_column_inner width=”1/2″][vc_column_text]
Maxima rientra nella categoria delle macchine confezionatrici verticali continue. Le sue principali caratteristiche sono elettronica avanzata, alta velocità, materiali pregiati. Si caratterizza per il principio della saldatura durante il traino del film (macchina continua a traslazione) ottenuto utilizzando una meccanica di estrema semplicità e robustezza. La manutenzione è minima: sfrutta l’uso di una centralina per la lubrificazione automatica e di un climatizzatore per il quadro elettrico. Velocità di produzione fino a 180 confezioni al minuto.
[/vc_column_text][/vc_column_inner][vc_column_inner][ultimate_spacer height=”50″][/vc_column_inner][vc_column_inner width=”1/2″][vc_column_text]
Caratteristiche meccaniche
[/vc_column_text][ultimate_spacer height=”15″][vc_column_text]
- Struttura di base in acciaio verniciato o inox AISI 304;
- Parti a contatto con il prodotto in acciaio inox AISI 304/316;
- Tubo formatore in acciaio inox di alto spessore;
- Barre di saldatura azionate con servomotore di ultima generazione e controllo assi integrato;
- Traino film con motorizzazione indipendente;
- Quadro elettrico climatizzato.
[/vc_column_text][ultimate_spacer height=”60″][vc_column_text]
Caratteristiche elettriche
[/vc_column_text][ultimate_spacer height=”15″][vc_column_text]
- Alimentazione elettrica 400 V trifase + neutro + terra;
- Consumo indicativo 6 KW;
- Controllo elettronico delle funzioni, realizzato mediante Motion Controller Siemens;
- Capacità di memoria: 100 programmi di lavoro;
- Diagnostica in grado di segnalare ogni tipo di anomalia;
- Sistema elettronico di misurazione e regolazione della lunghezza busta;
- Touch screen TFT.
[/vc_column_text][ultimate_spacer height=”60″][vc_column_text]
Sistemi di dosatura
[/vc_column_text][ultimate_spacer height=”15″][vc_column_text]
- Pesatrice multiteste;
- Dosatori volumetrici ad alta velocità;
- Dosatore a coclea;
- Contapezzi.
[/vc_column_text][/vc_column_inner][vc_column_inner width=”1/2″][vc_column_text]
Versioni speciali
[/vc_column_text][ultimate_spacer height=”15″][vc_column_text]
- Esecuzione in acciaio inox;
- Quadro separato e staccabile.
[/vc_column_text][ultimate_spacer height=”60″][vc_column_text]
Accessori principali
[/vc_column_text][ultimate_spacer height=”15″][vc_column_text]
- Fotocellula centratura stampa;
- Fondo quadro e soffietto;
- Iniezione gas;
- Stampatore;
- Otturatore per rifasamento prodotto;
- Fotocellula intasamento tramoggia;
- Etichettatrice;
- Buste eurohole;
- Centratura automatica film;
- Supporto bobina a espansione pneumatica;
- Giunzione facilitata e saldata;
- Supporto bobina doppia;
- Supervisione dei dati di produzione;
- Sistema di traino con cinghia sottovuoto.
[/vc_column_text][/vc_column_inner][/vc_row_inner][/vc_column][/vc_row][vc_row row_type=”row” use_row_as_full_screen_section=”yes” type=”grid” text_align=”left” css_animation=”” bg_type=”grad” ult_hide_row=”ult_hide_row_value” ult_hide_row_tablet=”tablet” ult_hide_row_tablet_small=”xs_tablet” ult_hide_row_mobile=”mobile” ult_hide_row_mobile_large=”xl_mobile” css=”.vc_custom_1498581575181{padding-top: 30px !important;padding-right: 60px !important;padding-bottom: 30px !important;padding-left: 60px !important;}” bg_grad=”background: -webkit-gradient(linear, left top, left bottom, color-stop(0%, #E7AA04), color-stop(99%, #C08B0F));background: -moz-linear-gradient(top,#E7AA04 0%,#C08B0F 99%);background: -webkit-linear-gradient(top,#E7AA04 0%,#C08B0F 99%);background: -o-linear-gradient(top,#E7AA04 0%,#C08B0F 99%);background: -ms-linear-gradient(top,#E7AA04 0%,#C08B0F 99%);background: linear-gradient(top,#E7AA04 0%,#C08B0F 99%);”][vc_column width=”1/3″ offset=”vc_hidden-md vc_hidden-sm vc_hidden-xs”][ultimate_spacer height=”55″][vc_column_text]
IDEALE PER…
[/vc_column_text][/vc_column][vc_column width=”2/3″ offset=”vc_hidden-md vc_hidden-sm vc_hidden-xs”][vc_tta_pageable no_fill_content_area=”1″ autoplay=”10″ active_section=”1″ css_animation=”bounceIn”][vc_tta_section title=”1″ tab_id=”1496997287857-f599b301-fbb7″][vc_row_inner row_type=”row” type=”full_width” use_row_as_full_screen_section_slide=”no” text_align=”left” css_animation=””][vc_column_inner width=”1/3″][vc_single_image image=”22″ img_size=”full” add_caption=”yes” alignment=”center” onclick=”custom_link” qode_css_animation=”” link=”https://www.mielepackaging.it/macchinari-per-pasta/”][vc_column_text]
Pasta
[/vc_column_text][/vc_column_inner][vc_column_inner width=”1/3″][vc_single_image image=”34″ img_size=”full” qode_css_animation=””][vc_column_text]
Verdura fresca
[/vc_column_text][/vc_column_inner][vc_column_inner width=”1/3″][vc_single_image image=”33″ img_size=”full” qode_css_animation=””][vc_column_text]
Snacks
[/vc_column_text][/vc_column_inner][/vc_row_inner][/vc_tta_section][vc_tta_section title=”2″ tab_id=”1496997858617-0bcf9662-1064″][vc_row_inner row_type=”row” type=”full_width” use_row_as_full_screen_section_slide=”no” text_align=”left” css_animation=””][vc_column_inner width=”1/3″][vc_single_image image=”427″ img_size=”full” add_caption=”yes” alignment=”center” onclick=”custom_link” qode_css_animation=”” link=”https://www.mielepackaging.it/macchinari-per-zucchero/”][vc_column_text]
Zucchero
[/vc_column_text][/vc_column_inner][vc_column_inner width=”1/3″][vc_single_image image=”426″ img_size=”full” onclick=”custom_link” qode_css_animation=”” link=”https://www.mielepackaging.it/macchinari-per-caffe/”][vc_column_text]
Caffè
[/vc_column_text][/vc_column_inner][vc_column_inner width=”1/3″][vc_single_image image=”428″ img_size=”full” onclick=”custom_link” qode_css_animation=”” link=”https://www.mielepackaging.it/macchinari-per-polveri-detergenti/”][vc_column_text]
Detergenti
[/vc_column_text][/vc_column_inner][/vc_row_inner][/vc_tta_section][vc_tta_section title=”3″ tab_id=”1496998083513-b3c508c7-08df”][vc_row_inner row_type=”row” type=”full_width” use_row_as_full_screen_section_slide=”no” text_align=”left” css_animation=””][vc_column_inner width=”1/3″][vc_single_image image=”195″ img_size=”full” add_caption=”yes” alignment=”center” qode_css_animation=””][vc_column_text]
Pet Food
[/vc_column_text][/vc_column_inner][vc_column_inner width=”1/3″][vc_single_image image=”196″ img_size=”full” qode_css_animation=””][vc_column_text]
Cosmetico & Farmaceutico
[/vc_column_text][/vc_column_inner][vc_column_inner width=”1/3″][vc_single_image image=”198″ img_size=”full” qode_css_animation=””][vc_column_text]
Dolciumi
[/vc_column_text][/vc_column_inner][/vc_row_inner][/vc_tta_section][vc_tta_section title=”4″ tab_id=”1496998238452-ec4f8957-7e48″][vc_row_inner row_type=”row” type=”full_width” use_row_as_full_screen_section_slide=”no” text_align=”left” css_animation=””][vc_column_inner width=”1/3″][vc_single_image image=”193″ img_size=”full” add_caption=”yes” alignment=”center” qode_css_animation=””][vc_column_text]
Formaggio
[/vc_column_text][/vc_column_inner][vc_column_inner width=”1/3″][vc_single_image image=”191″ img_size=”full” qode_css_animation=””][vc_column_text]
Alimenti freschi
[/vc_column_text][/vc_column_inner][vc_column_inner width=”1/3″][vc_single_image image=”52″ img_size=”full” qode_css_animation=””][vc_column_text]
Surgelati
[/vc_column_text][/vc_column_inner][/vc_row_inner][/vc_tta_section][/vc_tta_pageable][/vc_column][/vc_row][vc_row row_type=”row” use_row_as_full_screen_section=”yes” type=”grid” text_align=”left” css_animation=”” bg_type=”bg_color” css=”.vc_custom_1494516376002{padding-top: 30px !important;padding-right: 60px !important;padding-bottom: 30px !important;padding-left: 60px !important;}” bg_color_value=”#a5a5a5″][vc_column width=”1/3″][ultimate_spacer height=”20″][vc_column_text]
AREA DOWNLOAD
[/vc_column_text][/vc_column][vc_column width=”2/3″][ultimate_spacer height=”20″][vc_row_inner row_type=”row” type=”full_width” use_row_as_full_screen_section_slide=”no” text_align=”left” css_animation=””][vc_column_inner][vc_column_text][wpdm_category id=”maxima,” cols=”1″ toolbar=0 item_per_page=10 template=”link-template-default.php”][/vc_column_text][/vc_column_inner][/vc_row_inner][/vc_column][/vc_row]
Perchè sceglierla
Elevatissima velocità di produzione. Semplicità d’uso. Tempi di saldatura adattabili a film difficili. Alimentazione ottimizzata della linea confezionamento. Limitata richiesta di manutenzione e servizio. Facilità di accesso alle parti interne. Facile da pulire. Potente strumento industriale per produrre grossi volumi in tempi brevi in combinazione con dosatori volumetrici o multiteste.
Materiali d’incarto
Polipropilene, laminati ed accoppiati in genere, film a barriera, film idrosolubile, film di origine biologica e altri materiali termosaldabili come il polietilene.
Categorie
Confezionatrice verticale
MAXIMA
Maximum industrial performance[vc_row row_type=”row” use_row_as_full_screen_section=”no” type=”full_width” text_align=”left” css_animation=”” bg_type=”bg_color” bg_color_value=”#ffffff” css=”.vc_custom_1494509362085{padding: 20px !important;}”][vc_column][vc_row_inner row_type=”row” type=”full_width” use_row_as_full_screen_section_slide=”no” text_align=”left” css_animation=””][vc_column_inner width=”1/2″][vc_single_image image=”1358″ img_size=”full” onclick=”link_image” qode_css_animation=””][/vc_column_inner][vc_column_inner width=”1/2″][vc_column_text]
Maxima is in the category of continuous vertical packaging machines. These are its features: latest electronics, high speed, quality of materials. It is characterised
by the sealing during film drive principle (continuous motion machine) obtained by using very simple and strong mechanics. Minimum maintenance: it exploits the use of an automatic
lubrication control unit and a climate control unit for the electrical panel. Production speed up to 180 packages per minute.
[/vc_column_text][/vc_column_inner][vc_column_inner][ultimate_spacer height=”50″][/vc_column_inner][vc_column_inner width=”1/2″][vc_column_text]
Mechanical characteristics
[/vc_column_text][ultimate_spacer height=”15″][vc_column_text]
- Basic structure in painted steel or in AISI 304 stainless steel;
- Parts in contact with the product in AISI 304/316 stainless steel;
- Forming tube in very thick stainless steel;
- Sealing bars activated by a latest generation servo-motor, plus integrated axes control;
- Film drive with independent motorisation;
- Electrical panel with climate control.
[/vc_column_text][ultimate_spacer height=”60″][vc_column_text]
Electrical specifications
[/vc_column_text][ultimate_spacer height=”15″][vc_column_text]
- Electrical power supply 400 V 3-phase + neutral + earth;
- Indicative consumption 6 KW;
- Electronic control of functions, by Siemens Motion Controller;
- Memory capacity: 100 work programs;
- Diagnostics signalling any type of fault;
- Electronic system for measuring and adjusting bag length;
- Touch screen TFT.
[/vc_column_text][ultimate_spacer height=”60″][vc_column_text]
Dosing systems
[/vc_column_text][ultimate_spacer height=”15″][vc_column_text]
- Multi-head weigher;
- High speed volumetric dosing system;
- Screw dosing system;
- Counter.
[/vc_column_text][/vc_column_inner][vc_column_inner width=”1/2″][vc_column_text]
Special versions
[/vc_column_text][ultimate_spacer height=”15″][vc_column_text]
- In stainless steel;
- Separate removable panel.
[/vc_column_text][ultimate_spacer height=”60″][vc_column_text]
Main accessories
[/vc_column_text][ultimate_spacer height=”15″][vc_column_text]
- Print centring photocell;
- Square bottom and gusseted format;
- Gas injection;
- Printer;
- Timing hopper;
- Jammed hopper photocell;
- Labelling unit;
- Eurohole bags;
- Automatic film centring;
- Pneumatic expansion reel support;
- Facilitated and sealed splice;
- Double reel support;
- Production data collection;
- Drive system with vacuum belt.
[/vc_column_text][/vc_column_inner][/vc_row_inner][/vc_column][/vc_row][vc_row row_type=”row” use_row_as_full_screen_section=”yes” type=”grid” text_align=”left” css_animation=”” bg_type=”grad” ult_hide_row=”ult_hide_row_value” ult_hide_row_tablet=”tablet” ult_hide_row_tablet_small=”xs_tablet” ult_hide_row_mobile=”mobile” ult_hide_row_mobile_large=”xl_mobile” css=”.vc_custom_1498581575181{padding-top: 30px !important;padding-right: 60px !important;padding-bottom: 30px !important;padding-left: 60px !important;}” bg_grad=”background: -webkit-gradient(linear, left top, left bottom, color-stop(0%, #E7AA04), color-stop(99%, #C08B0F));background: -moz-linear-gradient(top,#E7AA04 0%,#C08B0F 99%);background: -webkit-linear-gradient(top,#E7AA04 0%,#C08B0F 99%);background: -o-linear-gradient(top,#E7AA04 0%,#C08B0F 99%);background: -ms-linear-gradient(top,#E7AA04 0%,#C08B0F 99%);background: linear-gradient(top,#E7AA04 0%,#C08B0F 99%);”][vc_column width=”1/3″ offset=”vc_hidden-md vc_hidden-sm vc_hidden-xs”][ultimate_spacer height=”55″][vc_column_text]
SUITABLE FOR…
[/vc_column_text][/vc_column][vc_column width=”2/3″ offset=”vc_hidden-md vc_hidden-sm vc_hidden-xs”][vc_tta_pageable no_fill_content_area=”1″ autoplay=”10″ active_section=”1″ css_animation=”bounceIn”][vc_tta_section title=”1″ tab_id=”1496997287857-f599b301-fbb7″][vc_row_inner row_type=”row” type=”full_width” use_row_as_full_screen_section_slide=”no” text_align=”left” css_animation=””][vc_column_inner width=”1/3″][vc_single_image image=”22″ img_size=”full” add_caption=”yes” alignment=”center” onclick=”custom_link” qode_css_animation=”” link=”https://www.mielepackaging.it/macchinari-per-pasta/”][vc_column_text]
Pasta
[/vc_column_text][/vc_column_inner][vc_column_inner width=”1/3″][vc_single_image image=”34″ img_size=”full” qode_css_animation=””][vc_column_text]
Fresh vegetables
[/vc_column_text][/vc_column_inner][vc_column_inner width=”1/3″][vc_single_image image=”33″ img_size=”full” qode_css_animation=””][vc_column_text]
Snacks
[/vc_column_text][/vc_column_inner][/vc_row_inner][/vc_tta_section][vc_tta_section title=”2″ tab_id=”1496997858617-0bcf9662-1064″][vc_row_inner row_type=”row” type=”full_width” use_row_as_full_screen_section_slide=”no” text_align=”left” css_animation=””][vc_column_inner width=”1/3″][vc_single_image image=”427″ img_size=”full” add_caption=”yes” alignment=”center” onclick=”custom_link” qode_css_animation=”” link=”https://www.mielepackaging.it/macchinari-per-zucchero/”][vc_column_text]
Sugar
[/vc_column_text][/vc_column_inner][vc_column_inner width=”1/3″][vc_single_image image=”426″ img_size=”full” onclick=”custom_link” qode_css_animation=”” link=”https://www.mielepackaging.it/macchinari-per-caffe/”][vc_column_text]
Coffee
[/vc_column_text][/vc_column_inner][vc_column_inner width=”1/3″][vc_single_image image=”428″ img_size=”full” onclick=”custom_link” qode_css_animation=”” link=”https://www.mielepackaging.it/macchinari-per-polveri-detergenti/”][vc_column_text]
Detergents
[/vc_column_text][/vc_column_inner][/vc_row_inner][/vc_tta_section][vc_tta_section title=”3″ tab_id=”1496998083513-b3c508c7-08df”][vc_row_inner row_type=”row” type=”full_width” use_row_as_full_screen_section_slide=”no” text_align=”left” css_animation=””][vc_column_inner width=”1/3″][vc_single_image image=”195″ img_size=”full” add_caption=”yes” alignment=”center” qode_css_animation=””][vc_column_text]
Pet Food
[/vc_column_text][/vc_column_inner][vc_column_inner width=”1/3″][vc_single_image image=”196″ img_size=”full” qode_css_animation=””][vc_column_text]
Cosmetic & Pharmaceutical
[/vc_column_text][/vc_column_inner][vc_column_inner width=”1/3″][vc_single_image image=”198″ img_size=”full” qode_css_animation=””][vc_column_text]
Sweets
[/vc_column_text][/vc_column_inner][/vc_row_inner][/vc_tta_section][vc_tta_section title=”4″ tab_id=”1496998238452-ec4f8957-7e48″][vc_row_inner row_type=”row” type=”full_width” use_row_as_full_screen_section_slide=”no” text_align=”left” css_animation=””][vc_column_inner width=”1/3″][vc_single_image image=”193″ img_size=”full” add_caption=”yes” alignment=”center” qode_css_animation=””][vc_column_text]
Cheese
[/vc_column_text][/vc_column_inner][vc_column_inner width=”1/3″][vc_single_image image=”191″ img_size=”full” qode_css_animation=””][vc_column_text]
Fresh food
[/vc_column_text][/vc_column_inner][vc_column_inner width=”1/3″][vc_single_image image=”52″ img_size=”full” qode_css_animation=””][vc_column_text]
Frozen foods
[/vc_column_text][/vc_column_inner][/vc_row_inner][/vc_tta_section][/vc_tta_pageable][/vc_column][/vc_row][vc_row row_type=”row” use_row_as_full_screen_section=”yes” type=”grid” text_align=”left” css_animation=”” bg_type=”bg_color” css=”.vc_custom_1494516376002{padding-top: 30px !important;padding-right: 60px !important;padding-bottom: 30px !important;padding-left: 60px !important;}” bg_color_value=”#a5a5a5″][vc_column width=”1/3″][ultimate_spacer height=”20″][vc_column_text]
AREA DOWNLOAD
[/vc_column_text][/vc_column][vc_column width=”2/3″][ultimate_spacer height=”20″][vc_row_inner row_type=”row” type=”full_width” use_row_as_full_screen_section_slide=”no” text_align=”left” css_animation=””][vc_column_inner][vc_column_text][wpdm_category id=”maxima,” cols=”1″ toolbar=0 item_per_page=10 template=”link-template-default.php”][/vc_column_text][/vc_column_inner][/vc_row_inner][/vc_column][/vc_row]
Wrapping materials
Polypropylene, laminates and coupled materials in general, barrier film, water-soluble film, film of biological origin, and other heat sealing materials such as polyethylene.
Why choose it?
Ultra high production speed. Easy to use. Sealing times can be adapted to difficult to work films; Optimised feeding to packaging line. Limited maintenance and servicing required. Easy access to internal parts. Easy to clean. A powerful industrial instrument for large volumes in a short time, combined with multi-heads or volumetric dosing system.
Categorie
Vertical packaging machine
